Lýsing
Tæknilegar forskriftir Inntak leið: Fljótandi og rafrænt vernd Leið: Staðall 12 leiðir Sjúklingur leka straumur: < 10 µA Inntaksviðnám: = 50 MO Tíðnissvar: 0.05 - 150 Hz (-3 - + 0,4 dB) Tímasamdráttur: = 3.2 s CMRR: >60 dB, > 100 dB (bæta síu) EMG truflunar síu: 25/35 Hz (-3 dB) Hitapappír: 210 mm x 30 m háhraða Pappírs hraði: - Sjálfvirk og taktur skráning: 25, 50 mm/s, ±5% - Handvirk skráning: 5, 6.25, 10, 12.5, 25, 50 mm/s, ±5% Næmnisval: - 2.5, 5, 10, 20, 40 mm/mV, ±5%. - Staðal næmni er 10 mm/mV ±0.2 mm/mV. Sjálfvirk skráning: Skref að skráningu samkvæmt.
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | II A |
| EAN | 6945040100492 |
| CND | Z12050301 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications Input way: Floating and defibrillation protection Lead: Standard 12 leads Patient leak current: < 10 µA Input impedance: = 50 MO Frequency response: 0.05 - 150 Hz (-3 - + 0,4 dB) Time constant: = 3.2 s CMRR: >60 dB, > 100 dB (adding filter) EMG interference filter: 25/35 Hz (-3 dB) Thermal paper: 210 mm x 30 m high-speed Paper speed: - Auto and rhythm record: 25, 50 mm/s, ±5% - Manual record: 5, 6.25, 10, 12.5, 25, 50 mm/s, ±5% Sensitivity selections: - 2.5, 5, 10, 20, 40 mm/mV, ±5%. - Standard sensitivity is 10 mm/mV ±0.2 mm/mV. Auto record: Record setup according to auto record format and mode, automatically changing leads, measuring and analyzing. Rhythm record: Record setup according to rhythm record format and mode, automatically measuring and analyzing. Manual record: Record setup according to manual record format, manually changing leads. Measurement parameters: HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1) Product safety type Class I CF defibrillation and pacing protection Size: 334x320x85 mm Power: - AC: 100-240 V, 50/60 Hz - DC: 14.8 V, 3700mAh rechargeable lithium battery
