Lýsing
Tæknilegar forskriftir Snertiskjár: Litur TFT LCD 13.3" Upplausn: 1920×1080 Max. bylgjur: 10 ECG ECG rásir: 5 leiðir CMRR: Skurðaðgerð, eftirlit, ST > 105dB / Greining > 90dB Tíðni: Greining: 0.05-150 Hz / Eftirlit: 0.5-40 Hz / Skurðaðgerð: 1-20 Hz / ST: 0.05-40 Hz Inntaksvídd: =10MO ECG skanna hraði: 6.25, 12.5, 25, 50 mm/s Prufuhraði: 500 Hz Næmni val: x1/8, x1/4, x1/2, x1, x2, x4, AUTO Hjörðartíðni: 15-350 bpm RESP Mælingarsvið: Barn: 0-150 rpm Fullorðinn: 0-120 rpm NIBP Mælingarsvið: 0~300 mmHg (0.0~40.0 kPa).
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | II B |
| EAN | 6941900600881 |
| CND | Z1203020201 |
| GMDN | 33586 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications Touchscreen display: Colour TFT LCD 13.3" Resolution: 1920×1080 Max. waveforms: 10 ECG ECG channels: 5 leads CMRR: Surgery mode, monitor mode, ST mode > 105dB / Diagnostic mode > 90dB Frequency: Diagnostic mode: 0.05-150 Hz / Monitor mode: 0.5-40 Hz / Surgery mode: 1-20 Hz / ST mode: 0.05-40 Hz Input impedance: =10MO ECG scan speed: 6.25, 12.5, 25, 50 mm/s Sampling rate: 500 Hz Sensitivity selection: x1/8, x1/4, x1/2, x1, x2, x4, AUTO Heart rate range: 15-350 bpm RESP Measuring range: Pediatric: 0-150 rpm Adult: 0-120 rpm NIBP Measuring range: 0~300 mmHg (0.0~40.0 kPa) Mode: Manual, Auto, NIBP STAT, Customized multi-cycle SpO2 Measuring range: 0% to 100% Temp Measuring range: 0°-50°C (32°-122°F) skin Memory: 8G internal SD card Data storage: NIBP recorder: 2000 sets / Trends data: 240 h / Events: 1000 sets Ports: 1 RJ45, 1 VGA, 2 USB, 1 multi-function Battery: rechargeable battery, 2750 mAh Operating time: more than 4 hours Size: 300x170x250 mm Weight: =4.3 kg Protection: IPX2, anti electricshock CF type Voltage: 100-240 V, 50/60 Hz
