Lýsing
Technical Specifications ECG acquisition • ECG channels: 12-lead (I, II, III, aVR-L-F, V1-6) • Patient cable: Standard 15D, 10-wires • CMRR: >100 dB • Input impedance: 100 MOhm • Sampling rate of the input stage: 32000 samples/second/channel • ECG resolution: 5µV/LSB; 500 s/s • Dynamic range: ± 325 mV • Bandwidth: Performance equivalent to 0,05-150 Hz • Pacemaker detection: Hardware detection coupled with convolution digital filtering • Filters: Linear phase digital diagnostic high-pass filter (acc. to 60601-2-25 2nd ed.) 50/60 Hz AC interference adaptive digital filter. Digital low pass filters at 25/40 Hz, for display and printing only • Defibrillation protection: AAMI/IEC standards • Front-end performance: ANSI/AAMI IEC 60601-2-25:2011 • Acquisition mode: Automatic (12-leads), Manual (3/6-leads), Stat (12-leads), Rhythm (1/3-leads) • Configuration: Standard or Cabrera • Lead fail detection: Independent on all leads • Heart rate meter: 30-300 bpm • ECG measurements: All leads, average, corrected; HR; Average RR; PR interval, QRS duration, QT interval and QTc interval, with hodges, Bazzet and Fridericia's formula max R[V5] or [V6] and S[V1], Sokolow-Lyon index; P, R, T axis • ECG interpretation: Glasgow Analysis Program for Adult, Pediatric, STEMI • ECG storage: 50 ECG • Export format: SCP-PDF • PC-ECG “Easy App”: ECG Management application for PC Display • Type: 5" TFT backlit colour LCD with capacitive touch panel • Resolution: 800x480 • Data: 3/6/12-leads real time Printer • Thermal printer head: 108 mm • Resolution: 8 dots/mm Physical characteristics • Device size/weight: 270x190x60 mm - 1.48 Kg Power • Power supply: 100-240V, 50/60 Hz • Degree of protection power supply: IP20 • Battery type: NiMH • Battery duration: more than 500 ECGs, more than 6 hours • Battery charging time: 4 hours to 85% full capacity Regulatory and safety • MDD 93/42/CEE Class IIa • IEC 60601-1-2 (electromagnetic compatibility): Group 1 - Class B • IEC 60601-1 (electrical safety) • Prote
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | II A |
| EAN | 8056732654983 |
| CND | Z12050302 |
| GMDN | 16231 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications ECG acquisition • ECG channels: 12-lead (I, II, III, aVR-L-F, V1-6) • Patient cable: Standard 15D, 10-wires • CMRR: >100 dB • Input impedance: 100 MOhm • Sampling rate of the input stage: 32000 samples/second/channel • ECG resolution: 5µV/LSB; 500 s/s • Dynamic range: ± 325 mV • Bandwidth: Performance equivalent to 0,05-150 Hz • Pacemaker detection: Hardware detection coupled with convolution digital filtering • Filters: Linear phase digital diagnostic high-pass filter (acc. to 60601-2-25 2nd ed.) 50/60 Hz AC interference adaptive digital filter. Digital low pass filters at 25/40 Hz, for display and printing only • Defibrillation protection: AAMI/IEC standards • Front-end performance: ANSI/AAMI IEC 60601-2-25:2011 • Acquisition mode: Automatic (12-leads), Manual (3/6-leads), Stat (12-leads), Rhythm (1/3-leads) • Configuration: Standard or Cabrera • Lead fail detection: Independent on all leads • Heart rate meter: 30-300 bpm • ECG measurements: All leads, average, corrected; HR; Average RR; PR interval, QRS duration, QT interval and QTc interval, with hodges, Bazzet and Fridericia's formula max R[V5] or [V6] and S[V1], Sokolow-Lyon index; P, R, T axis • ECG interpretation: Glasgow Analysis Program for Adult, Pediatric, STEMI • ECG storage: 50 ECG • Export format: SCP-PDF • PC-ECG “Easy App”: ECG Management application for PC Display • Type: 5" TFT backlit colour LCD with capacitive touch panel • Resolution: 800x480 • Data: 3/6/12-leads real time Printer • Thermal printer head: 108 mm • Resolution: 8 dots/mm Physical characteristics • Device size/weight: 270x190x60 mm - 1.48 Kg Power • Power supply: 100-240V, 50/60 Hz • Degree of protection power supply: IP20 • Battery type: NiMH • Battery duration: more than 500 ECGs, more than 6 hours • Battery charging time: 4 hours to 85% full capacity Regulatory and safety • MDD 93/42/CEE Class IIa • IEC 60601-1-2 (electromagnetic compatibility): Group 1 - Class B • IEC 60601-1 (electrical safety) • Prote
