Lýsing
Tæknilegar sérspecifikar: • Leið: Staðlar 12 leiðir • Öflunaraðferð: 12 leiðir samtímis • Næmni: 2.5, 5, 10, 20, mm/mV • Inntaksspenna: > 50 MO (10 Hz) • Síun: - EMG síun 25/35/45 Hz af - DFT síun 0.05/0.15/0.25/0.35/0.5/0.67 Hz - Lágpass síun 150/100/75 Hz - AC síun á/af • Skynjunaraðferð: Auto/Manual/Rhythm/R-R • Rhythm leið: Hver leið valin • Öryggisstaðall: IEC I/CF • Rafmagnsupply: - AC: 100 V - 115 V / 220 V - 240 V, 50/60 Hz - Endurhlaðanleg Li-ion rafhlaða: spennu 14.8 V - Meira en 6 klst. stöðugur rekstur með rafhlöðuframboði • Gagna geymsla: 500 ECG.
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | II A |
| EAN | 8023279333336 |
| CND | Z12050301 |
| GMDN | 16231 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications • Lead: Standard 12 leads • Acquisition mode: 12 leads simultaneously • Sensitivity: 2.5, 5, 10, 20, mm/mV • Input impedance: > 50 MO (10 Hz) • Filter: - EMG Filter 25/35/45 Hz off - DFT Fliter 0.05/0.15/0.25/0.35/0.5/0.67 Hz - Low pass filter 150/100/75 Hz - AC Filter on/off • Recording mode: Auto/Manual/Rhythm/R-R • Rhythm lead: Any lead selectable • Safety standard: I EC I/CF • Power supply: - AC: 100 V - 115 V / 220 V - 240 V, 50/60 Hz - Rechargeable Li-ion battery: voltage 14.8 V - More than 6 hours continuous operation with battery supply • Data storage: 500 ECG's • Thermal paper: rolled 80 mm x 20 m / folded 80 x 70 mm x 200 pages • Paper speed: 5 mm/s, 6.25 mm/s, 10 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s • Dimension: 290 x 220 x 85 mm • Weight: 2.5 kg without battery • Display: 320 x 240 pixels LCD (colour screen) • Selectable display language GB, IT, FR, ES, RU, PL, CZ, RO, DE, TR, HR, UA • Interface: Ethernet, RS232, USB • Barcode scanner support: yes • Report formats: PDF, Dicom, SCP, XML
