Lýsing
Tæknilegar forskriftir • Ytri stærð: 510 x 390 x 730 mm (B x H x D) • Kammarsstærð: 245 x 500 mm (Ø x dýpt) • Rekstrarspenna 230V - 50/60 Hz • Max afl: 2,200 W • Þyngd: 58 kg • Innbyggður prentari: JÁ • Handvirk lokun: JÁ • Festing fyrir pura deioniser: JÁ • PID kerfi: JÁ • Hringir: 121°C Vafið • Vinnslupressur min-max: 1.04 - 1.30 • Lágmarkstími heildarhrings*: 56 mínútur (25+18+13) • Hringir: 121°C Óvafið • Vinnslupressur min-max: 1.04 - 1.30 • Lágmarkstími heildarhrings*: 55 mínútur (25+18+12) • Hringir: 134°C Flash • Vinnslupressur min-max: 2.02 - 2.38
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | II B |
| EAN | 8023279356571 |
| CND | Z12011305 |
| GMDN | 42162 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications • External size: 510 x 390 x 730 mm (W x H x D) • Chamber size: 245 x 500 mm (Ø x dept) • Operating voltage 230V - 50/60 Hz • Max absorbed power: 2,200 W • Weight: 58 kg • Built in printer: YES • Manual closing: YES • Fitting for pura deioniser: YES • PID system: YES • Cycles: 121°C Wrapped • Working pressure min-max: 1.04 - 1.30 • Minimum time of the total cycle*: 56 minutes (25+18+13) • Cycles: 121°C Unwrapped • Working pressure min-max: 1.04 - 1.30 • Minimum time of the total cycle*: 55 minutes (25+18+12) • Cycles: 134°C Flash • Working pressure min-max: 2.02 - 2.38 • Minimum time of the total cycle*: 33 minutes (25+4+4) • Cycles: 134°C Wrapped • Working pressure min-max: 2.02 - 2.38 • Minimum time of the total cycle*: 43 minutes (25+5+13) • Cycles: 134°C Unwrapped • Working pressure min-max: 2.02 - 2.38 • Minimum time of the total cycle*: 42 minutes (25+5+12) • Cycles: 134°C Prion • Working pressure min-max: 2.02 - 2.38 • Minimum time of the total cycle*: 58 minutes (25+20+13) *The total time includes: vacuum, pre-heating time, cycle and drying phase. The times are to be intended for a fully loaded autoclave. All cycles have 3 stages of vacuum. Vacuum and pre-heating time can vary depending on the conditions of autoclave from 25 to 35 minutes.
