Lýsing
Tæknilegar forskriftir: Greiningarprinsipp: Endurspeglun ljósmyndun. Tími til niðurstaðna: = 2 mínútur. Minni með dagsetningu/tíma: 200 niðurstöður. Prófunartípa: Magntölur. Prófanir: CHOL, HDL, TRIG. Útreiknaðar prófanir: LDL, CHOL/HDL hlutfall, hjartasjúkdóma mat. Sýnismagn: 3-1 fitu próf tæki: 35 µL, CHOL einstaklingspróf tæki: 10 µL. Mælieiningar: mg/dL eða mmol/L. Mælingarsvið: - CHOL: 100-500 mg/dL (2.59-12.93 mmol/L) - HDL: 15-100 mg/dL (0.39-2.59 mmol/L) - TRIG: 45-650 mg/dL (0.51-7.34 mmol/L). Pc tengi fyrir gagnaflutning: Mini USB tengi. Kalibrering: Kóði Chip. Tungumál á skjánum: En.
Tæknileg gögn
| Tegund | IVD - Self Test |
| EAN | 0682607610907 |
| CND | W0201069080 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications Detection principle: Reflectance Photometry Time to results: = 2 minutes Memory with date/time: 200 results Type of test: Quantitative Tests: CHOL, HDL, TRIG Calculated tests: LDL, CHOL/HDL ratio, Cardiac Risk Assessment Specimen volume: 3-1 Lipid Panel Device: 35 µL, CHOL Individual Test Device: 10 µL Measurement units: mg/dL or mmol/L Measurement range: - CHOL: 100-500 mg/dL (2.59-12.93 mmol/L) - HDL: 15-100 mg/dL (0.39-2.59 mmol/L) - TRIG: 45-650 mg/dL (0.51-7.34 mmol/L) Pc interface for data transfer: Mini USB Port Calibration: Code Chip Languages on the screen: English abbreviations Power source: 4 AAA or AC Adaptor (Mini USB, 5V dc, 50 mA) Battery life: = 1,000 tests Automatic shut off: 5 minutes Meter dimensions - weight: 137×79×26 mm (5.4” x 3.1” x 1.0”) - 145 g (5.11 oz) Display dimensions: 50×50 mm (2.0” x 2.0”)
