Lýsing
Tæknilegar forskriftir. Ljósstyrkur við 1 m fjarlægð Lux 50,000 Litaskipti hitastig stillanlegt K° 4,000/4,500 ± 5% 9 LEDs W 2.0 hver (18 alls) Meðal líftími LED klukkustundir 60,000 CRI (litaskipti vísir) Ra 95 Þvermál lýsingarsvæðis Ø cm 28 Dýpt lýsingar IEC 60601-2-41 (L1+L2) við 60% af Ec cm 110 Heildar geislun Ec W/m2 186 Þvermál spegils cm 19.5 Notagildi lýsingarflatans cm2 63 Þyngd (þak, farartæki, vegg) kg 12 - 20 - 11 Orkuþörf V, Hz 100-240, 50-60 Lágmarks hæð rýmis (þak útgáfa) cm 254.5 Staðlar: IEC 60601-1 IEC 6.
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | I |
| EAN | 8023279491005 |
| CND | Z12010702 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications Light intensity at 1 m distance Lux 50,000 Colour temperature adjustable K° 4,000/4,500 ± 5% 9 LEDs W 2.0 each (18 total) Average LED life hours 60,000 CRI (chromatic rendering Index) Ra 95 Diameter of illuminated field Ø cm 28 Depth of illumination IEC 60601-2-41 (L1+L2) at 60% of Ec cm 110 Total radiated energy Ec W/m2 186 Diameter of the reflector cm 19.5 Useful lighting surface of the cupola cm2 63 Weight (ceiling, mobile, wall) kg 12 - 20 - 11 Power requirements V, Hz 100-240, 50-60 Minimum height of the room (ceiling version) cm 254.5 Standards: IEC 60601-1 IEC 60601-2-41, EU 2017/745, medical device of Class I
