Lýsing
Tækniskilgreiningar. Nefloftflæði mælingarsvið: 0-40 rpm ±2 rpm. SpO2 mælingarsvið: 0-100 % ±2 % (70-100 %), upplausn 1%. Púls hraði mælingarsvið: 30-250 bpm ±2 bpm eða ± 2% (veldu stærra). Viðnám gegn umhverfis ljósi: Munurinn á gildinu mælt í skilyrðum manngerðs ljóss og innandyra náttúrulegs ljóss og þess í myrkrinu er minna en ±1 %. Sýning: 1.8" lit LED. Rafmagnsnotkun: =100 mA. Rafmagnsupply: 3.7 V endurhlaðanleg lithium rafhlaða. Rafhlöðuvinnslutími: stöðugt vinna í meira en 20 klukkustundir. Öryggistýpa: Innri rafmagns, Tegund BF notaður hluti.
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | II A |
| EAN | 8023279336764 |
| CND | Z12080406 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications Nasal airflow measure range: 0-40 rpm ±2 rpm SpO2 measuring range: 0-100 % ±2 % (70-100 %), resolution 1% Pulse Rate measuring range: 30-250 bpm ±2 bpm or ± 2% (select the larger) Resistance to surrounding light: The difference between the value measured in the condition of man-made light and indoor natural light and that of darkroom is less than ±1 % Display: 1.8" colour LED Power consumption: =100 mA Power supply: 3.7 V rechargeable lithium battery Battery working hour: continuously work for more than 20 hours Safety Type: I nternally powered, Type BF applied part Dimension of device: 69x50x17.3 mm Weight: 100 g (lithium battery included)
