Lýsing
Tæknilýsing: Afhleðslubylgja: tvífasaskipt, straumstýrð púls. Orka (sjálfvirk stilling) 140-360 J. Handvirk orkustig: 5J, 10J, 20J, 30J, 50J, 100J, 200J, 300J, 360J. Hleðslutími: < 6 sek við 200 J. Hjartalínurit: handvirk virkjun, QRS merki. Hjartalínurit: Eindhoven I, II, III Goldberger, aVR, aVF, aVL. Viðnám sjúklings: 23-200 Ohm. Hjartsláttartíðni: 30-300 á mínútu. Púlsmæling: Nellcor Oximax. Hitaprentari: Upplausn: 200 dpi. Framrás: 25 mm/s, 50 mm/s. TFT LCD skjár: 115x86 mm (5.7"/144 mm) 320x240 pixlar. Rafskaut: límrafskaut, 3 ára geymsluþol.
Tæknileg gögn
| Tegund | Medical device |
| Flokkur (CE) | II B |
| EAN | 8023279353716 |
| GMDN | 48048 |
📄 Hlaða niður gagnablaði (PDF)
Lýsing á ensku
Technical Specifications Defibrillation Wave: biphasic, current controlled impulse Energy (automatic mode) 140-360 J Manual energy stages: 5J, 10J, 20J, 30J, 50J, 100J, 200J, 300J, 360J Charging time: < 6 sec at 200 J Cardio version: manual activation, QRS marker ECG Derivation: Eindhoven I, II, III Goldberger, aVR, aVF, aVL Patient's resistance: 23-200 Ohm Heart rate: 30-300 per min Pulse Oximeter Nellcor Oximax Thermal printer Resolution: 200 dpi Advance: 25 mm/s, 50 mm/s TFT LCD blue-mode monitor 115x86 mm (diagonal 5.7"/144 mm) 320x240 pixels Electrodes Adhesive electrodes, 3 years shelf life Cable length 3.5 m Save pads connect Data backup Removable memory 2 GB Power supply Voltage 90-264 V, 50/60 Hz Rechargeable Lithium-ion battery: Capacity 2.5 Ah Voltage: 13.2 Vdc Discharges 160-200 J Monitoring 5.30 h Charging time: 3.2 h Resuscitation guidelines AHA/ERC Standards IEC60601-1:1988+A1:1991+A2:1995 (Electrical Safety of Med. Electrical Devices) IEC60601-1-2:2001 (Electromagnetic compatib.) IEC60601-1-4:1996+A1:1999 (Programmable electrical medical systems) IEC60601-2-4:2002 (Defibrillators) EN1789:2003 (Ambulance standard) Protection class IP33
